Compact Power. Cosmic Speeds.
- Balance performance and portability in a compact size.
- The most powerful chip in Android tablets: Snapdragon 8 Elite.
- 9.06-inch OLED display with 2.4K high resolution.
- Enhanced 13-layer ICE-X cooling system.
- 8,200 mAh large battery with fast charging support.
- DTS:X Ultra 3D stereo, dual 1620 speakers, and dual 0815 X-axis linear motors.
Basic Parameters
Height: 134.2mm
Width: 207mm
Depth: 6.9mm
Weight: 370g
Material: Metal Middle Frame + Glass
Color: Starfrost (Silver), Eclipse (Black)
Memory Combination: Eclipse: 12 + 256 GB, 16 +512 GB, 24 GB + 1TB, Starfrost: 12 + 256 GB, 16 +512 GB
LPDDR5T + UFS 4.1 Pro
Display
Size: 9.06-inch OLED
Refresh Rate: Up to 165Hz
Touch Sampling Rate: Highest 2,000 Hz, Multi-Finger 240Hz
Resolution: 2,400 x 1,504 Pixels
Pixel Density: 313 PPI
Aspect Ratio: 16:10
Type: OLED
Brightness: 1,600 nits peak, 1,100 nits full-screen brightness
Material: Corning® Gorilla® Glass
Wide Color Gamut: DCI-P3
Color Accuracy ΔE ≈ 0.7 (Golden)
Eye Protection: SGS Certified
Splash, Water, and Dust Resistant: IP54 Rating
Cooling System
Enhanced ICE-X Cooling System
Under-Screen Cooling Alloy
Under-Screen High-Conductivity Graphene
Under-Screen High-Conductivity Copper Foil
Under-Screen Vapor Chamber
Motherboard Copper Foil
Motherboard Cooling System
High-Thermal-Conductivity Gel
Liquid Metal 2.0
Turbo Fan at 20,000 RPM
Durable High-Strength Aluminum Alloy Mid-Frame
Graphene Layer
High-Conductivity Copper Foil
Motherboard Vapor Chamber
Hardware
Snapdragon 8 Elite
CPU Cores: Oryon™
CPU up to 4.32GHz
GPU: Adreno™
RedCore R3 Pro
Capacity*
RAM: 12GB / 16GB / 24GB LPDDR5T
ROM: 256GB / 512GB / 1TB UFS4.1 Pro
*Actual memory space is less and varies due to many factors
Connectivity
Wi-Fi: 802.11 a/b/g/n/ac/ax
Bluetooth: Bluetooth 5.4
HDMI: Converter Needed
DP: Supports 2K HD Video
Cameras
Rear Camera
Resolution: 13MP, with Enhanced AI Algorithm
5P Lens, Up to 4K@30fps Video Recording
Front Camera
Resolution: 9MP, with Enhanced AI Algorithms
φ1.9mm - The Smallest Front Camera on a Tablet
4P Lens, 1080P@30fps
ƒ/2.2 aperture
0.7μm 4-in-1 Pixel
Sensors
Fingerprint Sensor, Electronic Compass, Gyroscope, Ambient Light Sensor, Accelerometer.
Operating System
REDMAGIC OS 10.5 Based on Android 15.0
Battery & Quick Charging
Battery: 8,200mAh Dual Cell Battery
Quick Charge: Support
Ports
Single Type-C port supporting fast charging, DisplayPort, and USB 3.2 Gen 2
Audio Supported Formats
Playback: WAV, AAC, MP3, FLAC
Storage: MP3, MPEG-4, Matroska, FLAC, 3GPP
Recording: MP3
DTS:X® Ultra. Stereo dual 1620 speakers
Video Supported Formats
Playback: MP4, MKV, WEBM
Recording: MP4
Video Codec Support
Decoder:
3840 × 2160 @ 240fps
4096 × 2160 @ 120fps
7680 × 4320 @ 60fps
8190 × 4320 @ 48fps
Encoder:
3840 × 2160 @ 120fps
7680 × 4320 @ 30fps
Image Supported Formats
Playback: JPEG, PNG, GIF, BMP, WBMP, HEIC
Storage: JPEG
Special Functions
Magic Key: By default, it launches the GameSpace, but users can customize it for quick access to other functions such as taking photos or recording videos with the rear camera, enabling the flashlight, launching the voice recorder, activating face-to-face translation, or switching to mute or vibration mode.
RGB Light: Fully Customizable Lighting Effects
Haptics: Dual 0815 X-axis Linear Motors
In the Box
REDMAGIC Astra Gaming Tablet ×1
Type-C Cable ×1
Warranty Card ×1
User Manual ×1
Logo Sticker ×1
Please note: Charger is not included with this tablet.
